BXS-FK-1000 handheld observation and attack integrated Interference equipment adopts the design concept of observation and attack integrated, which is a collection of detection and early warning and target orientation. The UAV control equipment integrating the functions of interference attack and display control network has the characteristics of small size, light weight and strong mobility. It can be used independently in a single set or multiple sets of networking applications, and has the functions of intelligent scheduling and integrated defense.
| Name | Parameter |
|---|---|
| Product Type | BXS-FK-1000 |
| Frequency Band | 30MHz ~ 6000MHz |
| Detection Distance | ≥3km |
| Detection Response Time | ≤4s |
| Detection Working Hour | <=5h |
| Detecting Number of Drones | >=10 |
| Multi-target Recognition | Support |
| Detection Angle | 360° |
| Beam Angle | <=±30° |
| Direction Finding Error | ≤10° |
| Interference Frequency Band | 1.5GHz, 2.4GHz, 5.8GHz (customizable) |
| Maximum Interference Bandwidth | 100MHz |
| Interference Distance | ≥2km |
| Interference Response Time | ≤3s |
| Standby Mode Working Hour | ≥5h |
| Charging Duration | 2h |
| Operation Temperature | -25ºC ~ 60ºC |
| Host Size | 760mm × 373mm × 100mm |
| Host Weight | ≤ 5kg (with battery) / ≤ 4kg (without battery) |
| Assembly Time | <=25s |
Integrated design with complete function, including early warning, direction finding, and attack capabilities.
Self-contained system that is fully functional for independent use or collaborative defense applications.
Flexible and convenient individual soldier handheld design: small size, light weight, and easy to carry.
Human trace engineering ergonomic design for handheld comfort and optimal application habits.
